Eltron P210
Full Color Plastic Card Printing Is Easier And More
Economical Than Ever Before.
The P210 can be used to add personalization to preprinted cards, or to print on blank plastic cards in full color or monochrome
black. Designed for single-sided edge-to-edge color printing, the P210 produces rich, vibrant color, with 300 dpi resolution for precise readable
bar codes, photos, graphics, and text.
Use the P210 for:
Adding text, bar codes or other personalization to preprinted plastic cards
Printing plastic gift cards and membership cards
Issuing photo ID badges
|
The Eltron P210 is ideal for printing personalized plastic cards in on-demand applications. Its ultra-quiet operation and
small footprint makes the P210 well suited for countertop applications where work space is at a premium. Operator friendly features include
front card loading and output, a quick-load ribbon cartridge for fast ribbon replacement, and an easy-to-change cleaning cartridge that thoroughly
remove dust before cards are printed.
Options include a magnetic stripe encoder for card applications that require encoded information. The P210 comes with two
dual interfaces; USB and Parallel, or USB and Serial, for easy integration into any system.
Eltron Plastic Card Printers are designed and manufactured to exacting ISO 9001:2000 standards for the utmost in quality and
dependability, and sold through a worldwide network of over 100 authorized resellers.
|
SPECIFICATION |
General Specifications |
Under 30 sec per card, full color single sided printing (YMCKO)
Card feeder capacity: 50 cards (30 mil)
Card Output Hopper capacity: 20 cards (30 mil)
2MB of Standard Memory, 1 MB Flash
Small footprint
OpenACCESS. clamshell design (Patent Pending)
Convenient front card loading and output
One 3-state LED and incorporated Multi-Function Button
Windows Drivers for 95/98, 2000 and NT 4.0
Bi-directional driver communication
Powerful EPCL (Eltron Printer Command Language) |
Color Printing |
Color dye sublimation or monochrome thermal transfer printing
Under 30 seconds per card (YMCKO)
300 dpi (11.8 dots/mm) print resolution |
Bar Codes |
Code 39
Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Interleave
UPC-A
EAN 8 & EAN 13
PDF-417 2D bar code |
Fonts |
Resident: Arial Bold 100
TrueType fonts available via Windows driver |
Card Specifications1 |
Types: PVC & Composite PVC
Card width/length: ISO CR-80 - ISO 7810, 2.125" (54mm) X 3.385" (86mm)
Option: Magnetic Stripe - ISO 7811
Card thickness: 30 mil |
Ribbon Specifications2 |
Ribbon Cartridge required
Black Monochrome: 500 cards/cartridge
YMCKO: 100 cards/cartridge
Auto ribbon detection system |
Bi-directional Communication Interface |
Centronics Parallel and USB
RS232 Serial and USB |
Mechanical
|
Without Card Feeder
Width: 7.16" (182mm)
Depth: 9.44" (240mm)
Height: 7.1" (180mm)
Weight: 6.4 lbs (2.9kg) |
With Card Feeder
Width: 7.16" (182mm)
Depth: 11.9" (303mm)
Height: 7.1" (180mm)
Weight: 6.4 lbs (2.9kg) |
Electrical |
110 - 230 Volts AC, 50/60 Hz
FCC Class A, CE, UL and CUL approved |
Environmental |
Operating Temperature: 60¢XF to 86¢XF (15¢XC to 30¢XC)
Operating humidity: 20% to 65% non condensing
Storage temperature: -23¢XF to 158¢XF (-5¢XC to 70¢XC)
Storage Humidity: 20% to 70% non-condensing
Ventilation: Free air |
Options |
Magnetic stripe encoder |
![](img/p310c.jpg) |
Eltron P310
Fast, Full-Color, High-Quality Plastic Card Printing
Has Never Been More Affordable
The P310 is ideal for applications requiring production of fullcolor plastic cards. Printing single-sided, personalized plastic
cards has never been simpler, faster, or easier. Use P310 Card Printers to print:
- Loyalty and membership cards
- Employee and visitor badges
- Student ID and access control cards
|
You can issue personalized cards on the spot, because the P310 prints sharp, readable bar codes, ID photos, graphics and text,
edge-to-edge, in seconds. Its space-saving, small footprint design is the perfect choice for desktop and countertop applications.
The P310 is truly user-friendly. Its easy-to-load, low maintenance design makes it simple for anyone to operate. Green, yellow
and red LED indicators provide easy-tounderstand printer status. Printer ribbon synchronization is automatic, eliminating the need for operator
intervention. An easy to change, self-cleaning cartridge thoroughly removes dust before printing minimizing missing dots and color registration
problems.
Eltron card printers, from Zebra Technologies, provide precise card printing, economical, reliable, easy-to-use operation,
plus the broadest product line of printers, options, accessories and supplies in the industry.
Eltron card printer products are available from authorized distributors and a network of authorized resellers in over 90
countries worldwide.
|
SPECIFICATION |
General Specifications |
High speed printing, 144 cards/hour, edge to edge, in full color
(YMCKO) throughput
2 MB image memory standard
Small footprint
Windows Drivers for 95/98, NT, 2000, ME
One year printer warranty
One year (unlimited passes) printhead warranty
Powerful EPCL (Eltron Printer Command Language) |
Color Printing
|
Color dye sublimation or monochrome thermal transfer printing
144 cards/hour (25 seconds per card), edge to edge, in full color (YMCKO)
300 dpi (11.8 dots/mm) print resolution
Edge to edge printing standard |
Bar Codes
|
Code 39
Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Industrial
UPC-A
EAN 8 & EAN 13
PDF-417 2D bar code and other symbologies available via Windows driver |
Fonts |
Resident: Arial Normal 100, Arial Bold 100
True Type fonts available via Windows driver |
Card Specifications
|
Types: PVC, Composite PVC
Card width/length: ISO CR-80 - ISO 7810, 2.125" (54mm) X 3.385" (86mm)
Option: Magnetic Stripe - ISO 7811
Option: Smart Card - ISO 7816-2
Card thickness: 10 mil (.25mm) to 60 mil (1.524mm)
Card Cartridge capacity: up to 210 cards (10 mil), up to 75 cards (30 mil)
Card Output Hopper capacity: up to 210 cards (10 mil), up to 75 cards (30mil) |
Ribbon Specifications
|
Monochrome: 1500 and 1000 cards/roll
Monochrome colors: black, red, blue, green, silver, gold,white, scratch-off gray
K Resin + O: 500 cards/roll
K Dye + O: 500 cards/roll
YMCKO: 350 cards/roll |
Overlay Varnish Specifications |
Thermal transfer
Clear and holographic options available:
- Clear |
- Genuine/Secure hologram |
- Pcard hologram |
- Custom holograms (various types available) |
|
Communications Interface |
Parallel standard (parallel cable included)
RS232C serial optional
USB option |
Mechanical 2 |
Width: 12.4¡¨ (315mm)
Depth: 7.75:¡¨(198mm)
Height: 8.7¡¨ (220mm)
Weight: 13.4 lbs (6.1kg) |
Electrical |
110 ~ 230 Volts AC, 50 / 60 Hz
FCC Class A, CE, UL and CUL approved |
Environmental |
Operating temperature: 60¢XF to 86¢XF (15¢XC to 30¢XC)
Operating humidity: 20% to 65% non condensing
Storage temperature: -23¢XF to 158¢XF (-5¢XC to 70¢XC)
Storage humidity: 20% to 70% non-condensing
Ventilation: Free air |
Options |
RS232C serial port (EPCL recommended for fast throughput)
USB port
Smart card contact station (30 mil cards only)
Magnetic encoder (30 mil card only)
Extended warranty program
Hot swap warranty program
Cleaning supplies
Service manual |
![](img/p420.jpg) |
Eltron P420
Dual-Sided, Edge-to-Edge Color Card Printing
Is Easier and Faster Than Ever
The Eltron P420 plastic card printer is highly versatile, and designed for high volume printing of dual-sided plastic cards
in color or monochrome. Use the P420 card printer to print:
- Employee ID, Time and Attendance cards
- Student ID and Facilities Access Control cards
- Club Membership and Loyalty cards
|
The P420¡¦s rugged, all metal enclosure houses a low-maintenance print mechanism that includes self-cleaning card handling,
high capacity ribbon system, two-line LCD control panel, and convenient card reject hopper. The reject hopper separates cards that fail encoding
prior to printing, saving valuable printer ribbon. The enclosure includes a viewing window to monitor the printing process without opening
the unit. Transparent input and output hoppers provide visual card capacity status.
The P420 is easy to load and use; the operator control panel displays printer status and functions that guide the operator,
using easy to understand status and simple instructions. Printer ribbon synchronization is automatic, eliminating the need for operator intervention.
A self-cleaning cartridge thoroughly removes dust before printing to help eliminate card rejects due to dust contamination.
Eltron card printers provide precise card printing, economical, reliable, easy-to-use operation, plus the broadest line of
options, accessories and supplies in the industry.
Eltron Plastic Card Printers are designed and manufactured to exacting ISO 9001:2000 standards for the utmost in quality and
dependability, and sold through a worldwide network of over 100 authorized resellers.
|
SPECIFICATION |
General Specifications |
High speed printing, over 102 cards/hour edge to edge in full color
(YMCKO/K) throughput
4MB image memory standard
Standard card flip over feature for dual sided printing
Reject card box feature
Small footprint
WindowsR Drivers for 95, 98, NT 4.0, 2000, ME
One year printer warranty with Hot Swap
One year printhead warranty (unlimited passes)
Powerful EPCL (Eltron Printer Command Language) |
Color Printing |
Color dye sublimation or monochrome thermal transfer printing
102 cards/hour throughput, 35 seconds per card, 2 sides (YMCKO/K)
300 dpi (11.8 dots/mm) print resolution
Edge to edge printing standard |
Bar Codes
|
Code 39
Code 128 B & C with & without check digit
2 of 5 & 2 of 5 Industrial
UPC-A
EAN 8 & EAN 13
PDF-417 2D bar code and other symbologies available via Windows drivers |
Fonts |
Resident: Arial Normal 22, Arial Bold 28
True Type fonts available via Windows drivers |
Card Specifications
|
Types: PVC, Composite PVC
Card width/length: ISO CR-80 - ISO 7810, 2.125" (54mm) X 3.385" (86mm)
Magnetic Stripe - ISO 7811
Smart Card ¡V ISO 7816-2
Card thickness: 10 mil (.25mm)3 to 60 mil (1.524mm)
Card Feeder capacity: up to 300 cards (10 mil), up to 100 cards (30 mil)
Card Output Hopper capacity: up to 300 cards (10 mil), up to 100 cards (30 mil) |
Ribbon Specifications |
Monochrome: 1500 and 1000 cards/roll
Monochrome colors: black, red, blue, green, silver, gold, white, scratch-off grey
K Resin + O: 500 cards/roll
K Dye + O: 500 cards/roll
YMCKO: 200 and 350 cards/roll
YMCKOK: 170 cards/roll |
Overlay Varnish Specifications |
Thermal transfer
Clear and holographic options available:
- Clear |
- Genuine/Secure hologram |
- Pcard hologram |
- Custom holograms (various types available) |
|
Communications Interface
|
Centronics Parallel standard (cable included)
RS232C Serial port (optional)
USB port (optional) |
Mechanical |
Width: 20.90" (523mm)2 Depth: 10.17" (254mm)
Height: 10.76" (269mm) Weight: 27.5 lbs (12,5 kg) |
Electrical |
110-230V, 50/60Hz
FCC Class A, CE, UL and CUL approved |
Environmental |
Operating temperature: 60¢XF to 86¢XF (15¢XC to 30¢XC)
Operating humidity: 20% to 65% non-condensing
Storage temperature: -23¢XF to 158¢XF (-5¢XC to 70¢XC)
Humidity: 10% to 90% non-condensing
Ventilation: Free air |
Options |
RS232C Serial port (EPCL recommended for fast throughput)
USB port
Smart Card contact station (30 mil cards only)
Magnetic encoder (30 mil cards only)
Extended warranty program
Hot Swap warranty program
Cleaning supplies
Service manual |
|
|
|
